Track stabilization coupling AKS 3004, Ø 50mm, SET
Product number:
1225155
Product information "Track stabilization coupling AKS 3004, Ø 50mm, SET"
Coupling Head AL-KO
AKS 3004, with anti-sway damping
Incl. Safety-Ball + Safety Compact + Bellow
Perm. gross weight 3000 kg
Nose load 150 kg
Drawbar-Ø 50 mm
Incl. reducer Ø 35 / 40 /45 mm
Hole horizontal Ø 12.1 mm
Hole vertical Ø 12.1 mm
Hole distance 50 + 54 mm
| Bohrung senkrecht (mm): | 12,1 |
|---|---|
| Bohrung waagrecht (mm): | 12,1 |
| Durchmesser (mm): | 50 |
| Form: | rund |
| Gewicht: | 5.4 |
| Hersteller: | AL-KO |
| Lochabstand senkrecht (mm): | 40 |
| Lochabstand waagrecht (mm): | 47 - 54 |
| Material: | Stahl |
| Stützlast (kg): | 150 |
| Typ: | AKS 3004 |
| zul. Gesamtgewicht (kg): | 3000 |
Login
Zubehör
FRIELITZ universal coupling box lock for anti-swin
FRIELITZ universal coupling box lock for anti-swinger clutches
• suitable for common ball couplings and anti-snatch couplings (not for Knott anti-snatch couplings)
• for the coupled and parked state, not for the drive operation
• Width customizable
• incl. Padlock with 2 keys
• packed in a box
Safety note: Not for driving. Before starting, check function and free space
The user is responsible for the correct use. We assume no liability for damage and loss.
There is a utility model protection for this product.
Product number:
012200099
Coupling head security device Safety Compact, AKS 3004
Coupling head security device AL-KO Safety Compact
suitable for coupling head AKS 3004
Product number:
1310892
Anti-theft device AL-KO, AKS3004
Anti-theft device AL-KO
type Safety Premium
suitable for coupling head AKS 3004
Product number:
1730541
